iGaging 12″ Layout Square – 36-LS-12

• 12″ square has a 13″ outside scale, 12″ inside scale plus a 5″ scale on the bottom & 1 3/8″ on the ends
• Outer rule is 16ths scale and has left to right and centering rule with small drilled holes every 1/16″
• Inner rule is 32nds scale and has left to right rule with small drilled holes every 1/8″
• Angle markings and drilled holes in the center from 5 to 60 in 5 increments plus a 22.5
• Aluminum base with blue anodized finish is 1/2″ tall and blades off set at 1/4″ and 3/8″ and a 45 cut out
• Squareness: 0.0002″ per inch
• Laser engraving on both sides of 2 mm blades
• Sets include a mechanical pencil and lead refills
• Supplied in protective box
