The Elmasonic E Plus series includes 9 units of different sizes and is characterized by simple, user-friendly operation. With 100% ultrasonic power at a frequency of 37 kHz, the Pulse function and visual warning (when bath temperature reaches the set limit), the Elmasonic E Plus solves typical cleaning tasks in the dental practice and dental laboratory quickly and efficiently. The activatable function Pulse is suited to remove tenacious, mineral soiling and polishing pastes. The Elmasonic E Plus Superior cleaning technology Comparison of Sweep and Pulse effects Application examples before and after cleaning ultrasonic power is increased up to 20%, so that any soiling will be removed easily and quickly. The limit temperature can be adjusted according to individual requirements. When the set temperature limit is reached the unit gives out a visual warning that helps to prevent the coagulation of proteins and protects sensitive items from damage due to high temperatures.

ELMASONIC E PLUS SERIES FEATURES

• Easily operated, mastered in minutes
• Fast, thorough cleaning or mixing at 37 kHz ultrasonic frequency
• Select your tank size from 8 capacities
• Durable lid helps reduce sound, solution evaporation and serves as a drip tray
• Cavitation-resistant stainless steel tank
• Ergonomic handles make it easy to move
• Side mounted drain valve and port (EP60H units and larger) to remove spent solution
• Superior German engineering
• Replacement warranty in year 1; parts and labor year 2
• Practical optional accessories for special tasks

Elmasonic Easy PLUS Ultrasonic Cleaner Comparison Chart Model Part No Drain Temp. Heat Power Vol. (gal.) Tank Size (“) Ultrasonic Frequency Ultrasonic Power EP10 107 1649 No No 60W 0.2 7.5 x 3.3 x 2.4 37kHz Sweep / Pulse 30W EP10H 107 1647 No 80C 60W 0.2 7.5 x 3.3 x 2.4 37kHz Sweep / Pulse 30W EP20H 107 1653 No 80C 120W 0.5 5.9 x 5.4 x 3.9 37kHz Sweep / Pulse 35W EP30H 107 1657 No 80C 200W 0.75 9.4 x 5.4 x 3.9 37kHz Sweep / Pulse 80W EP40H 107 1665 No 80C 200W 1 9.4 x 5.4 x 5.9 37kHz Sweep / Pulse 140W EP60H 107 1667 Yes 80C 400W 1.5 11.8 x 5.9 x 5.9 37kHz Sweep / Pulse 150W EP100H 107 1670 Yes 80C 400W 2.5 11.8 x 9.4 x 5.9 37kHz Sweep / Pulse 150W EP120H 107 1672 Yes 80C 800W 3.5 11.8 x 9.4 x 7.9 37kHz Sweep / Pulse 200W EP180H 107 1674 Yes 80C 800W 5 12.9 x 11.8 x 7.9 37kHz Sweep / Pulse 200W EP300H 107 1676 Yes 80C 1200W 7.5 19.9 x 11.8 x 7.9 37kHz Sweep / Pulse 300W

Product Manual
